9'' LED Combination Driving Lamp

  • High Power 9W LEDs for exceptional performance (reference no. 30)
  • Optimal illumination provides excellent visibility
  • Increases driver’s safety and comfort with less eye fatigue
  • Engineered to withstand extreme vibration, shock, dust, and water immersio
  • Perfected heat management for long-lasting performance
  • Aluminum alloy housing for ultra-light weight (2450g)
  • Suitable for extreme terrain and climate
  • Complies with E-mark regulations
Feature
  • Part No.
  • Regulation
  • IP Rating
  • Markets
  • Shape
  • Voltage
  • Function
  • Mounting Type
  • SMD LEDs
  • Watts
  • Raw Lumen
  • Effective Lumen
  • HV CD
  • Current Draw
  • Connection
  • Temperature
  • Lens
  • Housing
  • Bracket
  • Hardware
    • 22836-B

    • EMC
    • IP66
    • Heavy Duty Truck
    • Round
    • 9~32V
    • Driving lamp│DRL
    • Bracket Mounting
    • 5
    • 50
    • 3000
    • 1800
    • 130000
    • 13.5V at 3.34A±0.31A
      28V at 1.72A±0.021A
    • 300mm cable
    • -30°C~50°C
    • PC
    • Aluminum
    • Zinc cast
    • Stainless steel
