22890
9'' LED Auxiliary Driving Lamp
- Developed uniquely by Lucidity with additional features: high beam, front position, auxiliary floor lamp
- Outstanding performance with reference number 40
- Offer great night vision with build-in auxiliary floor lamp and new optic design to enhance road user’s safety
- Made to withstand severe environmental conditions
- Identified easily with light guide front position lamp
Feature
- Part No.
- Regulation
- IP Rating
- Markets
- Shape
- Voltage
- Mounting Type
- SMD LEDs
- Watts
- Raw Lumen
- Effective Lumen
- HV CD
- Reference No.
- Current Draw
- Connection
- Temperature
- Lens
- Housing
- Bracket
- Hardware
-
-
22890
- EMC │ ECE
- IP69K
- Heavy Duty Truck
- Rectangular
- 9~32V
- Bracket Mounting
- 4
- 21
- 2500
- 1600
- 180000
- 40
- 13.5V at 1.45±0.2A
28V at 0.7±0.1A - 300mm cable
- -30°C~50°C
- PC
- Aluminum
- Zinc cast
- Stainless steel
-
