22807
Flood Beam LED Work Lamp
- Provides brightness and safety work environment
- Lamp includes a stainless steel swivel bracket, bolts and washers for easy installation
- Even fading pattern without hotspots
- Epoxy encapsulated electronics
- Low power consumption
- ADR approval version available upon request
Feature
- Part No.
- Regulation
- IP Rating
- Markets
- Shape
- Voltage
- Mounting Type
- Light Pattern
- SMD LEDs
- Watts
- Raw Lumen
- Effective Lumen
- HV CD
- Current Draw
- Connection
- Temperature
- Lens
- Housing
- Bracket
- Hardware
-
-
22807DT
- ECE │ EMC
- IP69K
- Heavy Duty Trailer │ Construction
- Rectangular
- 9~32V
- Bracket Mounting
- Flood
- 9
- 22
- 2160
- 1490
- 4100
- 13.5V at 1.5A±0.25A
28V at 0.73A±0.12A - Built-in Deutsch connector
- -40℃~60℃
- PC
- Aluminum
- Stainless Steel
- Stainless Steel
-
-
-
22807-B
- EMC
- IP69K
- Agriculture │ Construction
- Rectangular
- 9~32V
- Bracket Mounting
- Flood
- 9
- 22
- 2160
- 1490
- 4100
- 13.5V at 1.5A±0.25A
28V at 0.73A±0.12A - 280mm cable
- -40℃~60℃
- PC
- Aluminum
- Stainless Steel
- Stainless Steel
-
